Technical Specifications

The product features are precision crafted to deliver exceptional performance and aesthetics.

Pixel Pitches

P0.99 mm, P1.06 mm, P1.26 mm, P1.39 mm

Size (mm)

2421.2×1461.8×28.5, 2674×1610×28.5, 2880×1620×28, etc

Resolution

1920×1080

Brightness/nit

200-1000 Adjustable

Color Temperature (K)

500-10000 Adjustable

Contrast Ratio

7000:1

Refresh Rate (Hz)

3840

Viewing angle (H/V)

170°/170°

Color Depth (bit)

16

Material

Aluminum Alloy, Die-casting Aluminum/Aluminum Magnesium Alloy

Installation Method

Portable Stand, Ground Stacking, Wall Mounted, Hanging

Max Power Consumption (KW)

2.05 (common cathode)

Input Power Voltage (V)

AC220V±15% 50/60 Hz

Weight/Cabinet (kg)

≤94

Input Interface

HDMI 1.3×2, USB2.0×1 (expandable up to 3), USB3.0×1, Gigabit network port×1

Output Interface

HDMI 1.3 LOOP×1, Fiber optic audio SPDIF×1, Audio 3.5mm×2

Functional Audio

2×15W Speaker

Controller with Bluetooth

Supports adjustment of brightness, volume, colour temperature, signal switching, standby, etc

Operating System

The desktop UI system customized based on Android 11, can add third-party app applications
