Technical Specifications

The product features are precision crafted to deliver exceptional performance and aesthetics.

Pixel Pitches

P1.25 mm, P1.53 mm, P1.86 mm, P1.99 mm, P2.5 mm

LED Type

Top 1010, Top 1212, Top 1515, Top 1817, Top 2121

Module Resolution (W×H Pixel)

256×128, 208×104, 172×86, 160×80, 128×64

Module Dimension (mm)

320×160

Pixel/m²

640,000, 422,500, 288,906, 250,000, 160,000

No. of Modules/Cabinet

2×3

Servicing

Front/Rear

Cabinet Size (W×H×D)

640mm×480×49mm

Cabinet Area (m²)

0.3072

Cabinet Material

Die-Cast Aluminum

Cabinet Resolution

512×384, 416×312, 344×258, 320×240, 256×192

Weight (KG)

≤7 KG

Contrast Ratio

5000:1

Colour Temperature (K)

5000-10000 Adjustable

Brightness (nits)

≥600-800

Viewing Angle (H/V)

≥160°/≥160°

Max Power Consumption (W/m²)

≤450 (Common Cathode)

Average Power Consumption (W/m²)

≤250

Input Power Voltage

AC220V±15%

Drive Mode

Constant Current Drive

Frame Rate (Hz)

30-120 Hz

Refresh Rate (Hz)

≥3840 Hz

Colour Depth (bits)

16 bit

Life Span (Hrs)

100,000

Operating/Storage Temp (°C)

-10+45/-20+60

Operating/Storage Humidity (RH)

10-90%/10-70%

IP Rating

IP3X, IP5X with QCOB
